Gocycle
®
Owner’s Manual for G3, March 2016
© Karbon Kinetics Limited. All Rights Reserved. 82
Using right angle circlip pliers or
a pin spanner, tighten the
headset pre load tophat to 8-12
Nm.
NOTE: NEVER TIGHTEN OR
ADJUST THE HEADSET PRE
LOAD TOPHAT UNLESS THE
FORK CROWN BOLTS ARE
LOOSE.
Ensuring that the front fork and
handlebars are aligned, tighten
the two fork crown bolts to 10-12
Nm. NOTE: You will need to
recheck both bolts twice to
ensure that torque is even
between each bolt. Replace the
rubber dust boot.
7.13
Adjusting the Stem Quick Release Lever
It is unlikely that you will need to adjust Steam Quick Release Lever, however in the event that you
need to replace the lever you will need to adjust the clock nut on the opposite side of the stem
adjuster to ensure the quick release lever closes with the correct force.
