Godex RT700 SERIES Service Manual

9
Code
Material Code
Product Name
Quantity
Remarks
87
765-130064-142
MACHINE SCREW,P,NI,M3*6,SPW ONLY,#10-3173-01
2
RT700i/RT700iW/
RT700i+
RT700x 用量為 4
88
765-130084-141
MACHINE SCREW,P,NI,M3*8,SPW/FWΦ8,#10-3174-01
6
89
765-220104-245
TAPPING SCREW,P,BK,2.0*10,TAP III
1
90
765-226064-108
TAPPING SCREW,P,NI,Φ6FW,Φ2.6*6,TAP III
3
91
765-230054-245
TAPPING SCREW,P,BK,3*5,TAP III,#10-3177-01
5
92
765-230084-108
TAPPING SCREW,P,NI(FW)Φ3*8,TAP
III,#1-092430-00,#10-3179-01
5
93
765-230087-445
TAPPING SCREW,F,ZN,3*8,TAP III,#10-3180-01
2
94
775-230816-053
GRAPHITE WASHER,Φ8.1*Φ16*0.5t/mm,#10-3182-01
2
95
775-620307-063
E-RING,Φ3.0*Φ7.0*0.6t/mm,#1-092406-00,#10-3183-01
6
96
775-620409-063
E-RING,Φ4.0*9.0*0.6t/mm(BK),1-092401-00,#10-3184-01
3
97
775-620612-082
E-RING,Φ6.0*Φ12*0.8/mm,#10-3186-01
1
98
775-C61523-053
GRAPHITE WASHER,Φ23*Φ15.2*0.5t/mm,#17-3192-01
1
99
219-114240-422
TPH,KPC-108-8TAE1-GO2,936ohms,200DPI,4",24V,KC66,
4 Lock Hole
1
RT700i/RT700iw/
RT700i+/RT700x
100
745-006400-000
Anti-Static Brush,115.5mm,RT700
1
101
227-106022-040
HOUSING,PH2.0-06P,PH2.54-04P,UL1007,AWG26,160mm,
#16-xxxx-01
1
RT700i/RT700iW/
RT700i+/RT700x
102
765-226044-148
TAPPING SCREW,P,NI,Φ6FW,Φ2.6*4,TAP III,#10-3176-01
1
103
745-006100-000
PC Plate,Φ29.5*0.254t,Mach 5
1
104
765-230104-108
TAPPING SCREW,P,NI(FW)Φ3*10,TAP III,#10-3189-01
5
105
217-000020-00D
CORE,B15 UH,13x23x7(0730A)
2
106
223-400002-001
COIN CELL BATTERY,3V,BCR-1225
1
107
325-024000-203
Ribbon & Label Installation,RT700
1
108
325-024200-003
Unlock Sign Label,0.15t,RT700
1
109
227-106022-040
HOUSING,PH2.0-06P,400mm,UL1061#28AWG
1
RT700i
111
775-320306-052
INTERNAL WASHER,Φ3*Φ6.5*0.5t,#1-092422-00
1
112
765-230154-108
TAPPING SCREW,P,NI(FW)Φ3*15,TAP II
2
113
227-110015-040
HOUSING,PH2.0-2*5P/PH2.0-2*6P,400mm,UL1061#28AW
G
1
RT700iW/RT700i+
114
227-116017-040
PH2.0-16P/2.0-2*15P,580mm,UL1007,#26 & UL1095,#28
1
RT700
115
700-106100-001
Bottom Case,RT860i
1
RT700w/RT700iW/
RT700i+

Godex RT700 SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Max Print Speed	5 ips
Max Print Length	1727 mm (68")
Processor	32-bit RISC
Interface	USB, Serial, Ethernet
Media Type	Continuous, Die-cut, Fan-fold
Media Width	25.4 mm - 118 mm (1" - 4.64")
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	127 mm (5")
Ribbon Width	30 mm - 110 mm (1.18" - 4.33")
Power	100-240V AC, 50/60Hz
Dimensions	285 mm (L) x 210 mm (W) x 171 mm (H)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
