Godex RT700 SERIES Service Manual

8
Code
Material Code
Product Name
Quantity
Remarks
55
715-017505-101
SPUR GEAR,75T,M0.5,IDΦ4
1
56
715-025520-100
DOUBLE GEAR,55/20T,M0.5*7.5t
1
57
720-060400-010
Hinge fix pin,nickel,EZ-DT-4
2
58
720-068300-000
Hook Shaft,RT700
1
59
720-068400-000
Ribbon tension adjuster,RT700
1
60
720-068500-000
Ribbon Rewinder Shaft,RT700
1
61
725-036000-001
Fix spacer,#17-3190-01,EZ-1000
1
62
725-081800-001
Motor Bracket(PM),RT700
1
RT700/RT700w
63
725-081900-001
Motor Bracket(Hybrid),RT700
1
RT700i/RT700iW/
RT700x/RT700i+
64
725-082000-001
Ribbon Tension Adjuster,RT700
1
65
725-082100-011
TPH Bracket,RT700
1
66
725-082200-001
Ribbon Supply Washer,RT700
1
67
730-001400-000
Platen Bushing,RT200
2
68
745-005200-000
Wool,Φ8.2*Φ25*2t,#13-2479-01
1
69
745-000800-000
Wool fiber,Φ24*15.3*2.0t,mm
1
70
750-005900-000
TPH SPRING,(C)D5.2*D0.7*12L*7N,#1-092230-00
4
71
750-028700-000
RIBBON SUPPORT SPRING,(C)D3.5*D0.5*10L*7N
2
72
750-037900-010
Spring,(C)D16*D20*17.2L*4N
1
73
750-031500-000
RIBBON COMPRESSION SPRING, (C) D12.5*D1.0*14L*5N
1
74
750-035400-000
TPH SPRING,(C)D6.0*D1.0*19L*8N
2
75
750-035700-000
Spring,Ribbon Rewind,#17-3175-01,D22.5*D0.8*6N
1
76
750-036000-000
Spring,Label Roll Holder
Extend,#17-3180-01,D6.0*D0.5*60L
1
77
750-036200-000
Spring,Dancer,#17-3182-01,D7.0*D0.8*3N
1
78
750-036500-000
Compress Spring,ribbon
Supply,#17-3184-01,D8.5*D1.2*10.2L*4N
1
79
755-010500-010
Overlay Label,GoDEX,No model name
1
RT700/ RT700w
80
755-010800-010
Overlay Label(LCD),GoDEX,No model name
1
RT700i/RT700iW/
RT700i+
83
760-000200-001
RUBBER FOOT,#1-092207-00 & #17-3195-01
4
84
760-006400-002
SPRING PIN,Φ2.5*16L,#17-3194-01
1
85
760-006700-002
ONE WAY CLUTCH,#17-3191-01
1
86
765-130054-142
MACHINE SCREW,P,NI,M3*5,SPW ONLY,#1-092429-00
2

Godex RT700 SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Max Print Speed	5 ips
Max Print Length	1727 mm (68")
Processor	32-bit RISC
Interface	USB, Serial, Ethernet
Media Type	Continuous, Die-cut, Fan-fold
Media Width	25.4 mm - 118 mm (1" - 4.64")
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	127 mm (5")
Ribbon Width	30 mm - 110 mm (1.18" - 4.33")
Power	100-240V AC, 50/60Hz
Dimensions	285 mm (L) x 210 mm (W) x 171 mm (H)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
