Godex RT700 SERIES Service Manual

44
3-19 Spare Parts List
No.
Item No.
Item Name
Pg.
Note
1
021-70i004-000
RT700i TPH Spare Parts
P13
2
021-R70004-000
RT700 Platen Spare Parts
P17
3
021-70i003-000
RT700i Motor Spare Parts (RT700i/RT700iW/RT700x/RT700i+)
P19
4
021-R70003-000
RT700 Motor Spare Parts
5
021-70i001-000
RT700i Mainboard Module Spare Parts (Programmed FW) USB LAN RS232
USBH
P24
6
021-70i001-490
RT700i Mainboard Module Spare Parts (Programmed FW) USB LAN RS232
USBH
7
021-R70002-000
RT700 Mainboard Module Spare Parts (Programmed FW) USB LAN RS232
8
021-R70007-000
RT700x Mainboard Module Spare Parts (Programmed FW) USB LAN
RS232 USBH
9
021-823002-000
MAIN BOARD PCBA PARTS,GoDEX,RT823i/RT833i/RT700iW/RT730iW
10
021-70i001-00P
MAIN BOARD PCBA PARTS,RT700i+,USB,LAN,RS232,USBHx3,BT
11
021-70i005-000
RT700i Switching Power Adapter Spare Parts
P34
12
021-R70005-000
RT700 Print Frame Hook Spare Parts
P35
13
021-R70008-000
RT700 Main Frame Hook Spare Parts
P36
14
021-R70009-000
RT700 Label Holder Spare Parts
P37
15
021-R70010-000
RT700 One Way Clutch Holder Module Spare Parts
P38
16
031-R70001-000
RT700 Peeler Module Spare Parts
P39
17
031-R70002-001
RT700 4” Cutter Module (RGG120-VE Whole Cut) Module Spare Parts
P40
18
031-70i001-001
RT700i Wireless Bluetooth Module (Metal Cover) Module Spare Parts
P41

Godex RT700 SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Max Print Speed	5 ips
Max Print Length	1727 mm (68")
Processor	32-bit RISC
Interface	USB, Serial, Ethernet
Media Type	Continuous, Die-cut, Fan-fold
Media Width	25.4 mm - 118 mm (1" - 4.64")
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	127 mm (5")
Ribbon Width	30 mm - 110 mm (1.18" - 4.33")
Power	100-240V AC, 50/60Hz
Dimensions	285 mm (L) x 210 mm (W) x 171 mm (H)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
