Godex RT700 SERIES Service Manual

7
Code
Material Code
Product Name
Quantity
Remarks
23
700-084500-011
Top Cover,RT700
1
24
700-084600-021
Print frame shelf,RT700
1
25
700-084700-031
Main Frame Base,RT700
1
26
700-084800-001
Bottom Case,RT700
1
RT700/RT700i/RT
700x
27
700-084900-001
Ribbon Window Cover,RT700
1
28
700-085000-001
Window,RT700
1
RT700/RT700W/R
T700x
29
700-085100-011
Window LCD,RT700
1
RT700i/RT700iW/
RT700i+
30
700-085200-001
Bottom Front Panel,RT700
1
31
700-085300-011
Main Frame Cover,RT700
1
32
700-085400-001
Label Roll Holder-LH,RT700
1
33
700-085500-011
Label Roll Holder-RH,RT700
1
34
700-085600-001
Label Roll Holder Cover-LH,RT700
1
35
700-085700-001
Label Roll Holder Cover-RH,RT700
1
36
700-085800-011
Label Path Plate,RT700
1
37
700-085900-001
TPH Cove,RT700
1
38
700-086000-001
Hook-L,RT700
1
39
700-086100-001
Hook-R,RT700
1
40
700-086200-001
Ribbon Supply Wheel,RT700
1
41
700-086300-001
Ribbon Rewind Wheel,RT700
1
42
700-086400-001
One Way Clutch Holder,RT700
1
43
700-086500-001
Label Guide Stopper,RT700
1
44
700-086600-011
Ribbon Supply Rewind Cap,RT700
1
45
700-086700-001
Damper,RT700
1
46
700-086800-001
Damper Holder,RT700
1
47
700-086900-001
Damper Holder Plate,RT700
1
48
705-004200-010
PLATEN Φ14,RT700
1
49
715-012305-200
GEAR,23T*M0.5*5.5t,Black
1
50
715-013205-100
SPUR GEARM,32T*M0.5*4.0t,#1-09222-00
1
51
715-015205-200
SPUR GEAR,BLACK,52T*M0.5*4.0t
1
52
715-015605-100
GEAR,56T*M0.5*4.0t,DΦ4.0
1
53
715-015905-100
GEAR,59T*M0.5*11.9t,DΦ8.0
1
54
715-016405-102
SPUR GEAR,64T*M0.5*5.5t,DΦ15
1

Godex RT700 SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Max Print Speed	5 ips
Max Print Length	1727 mm (68")
Processor	32-bit RISC
Interface	USB, Serial, Ethernet
Media Type	Continuous, Die-cut, Fan-fold
Media Width	25.4 mm - 118 mm (1" - 4.64")
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	127 mm (5")
Ribbon Width	30 mm - 110 mm (1.18" - 4.33")
Power	100-240V AC, 50/60Hz
Dimensions	285 mm (L) x 210 mm (W) x 171 mm (H)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
