Godex RT700 SERIES Service Manual

6
Code
Material Code
Product Name
Quantity
Remarks
01
160-000227-000
51-2468-00,RIBBON SENSOR BOARD ASS'Y,Mach 5
1
02
160-000243-004
LCD BOARD ASS'Y,RT200i
1
RT700i/RT700iW/
RT700i+
03
160-000256-001
FEED & SW BOARD ASS'Y,RT200
1
RT700/RT700W
/RT700x
04
160-000259-000
SEE-THROUGH SENSOR BOARD ASS'Y,RT200,RT700
1
05
160-000260-001
BLACK MARK SENSOR BOARD ASS'Y,RT200,RT700
1
06
160-000257-003
MAIN BOARD ASS'Y,USB+LAN+RS232,RT700
1
RT700
160-000257-013
MAIN BOARD ASS'Y,USB+LAN+RS232+USBH,RT700i
1
RT700i/RT700x
160-000285-000
MAIN BOARD ASS'Y,USB,RS232,LPT,RT700(730)
1
RT730
160-000315-001
MAIN BOARD ASS'Y,USB,LAN,RS232,LPT,USBH+BT,RT860i
1
RT700w/RT700iw/
RT700i+
160-000335-020
MAIN BOARD
1
RT700i+
07
160-100017-000
DOOR OPEN SW ASS"Y,EZ-1000
1
08
219-114240-712
TPH,KPZ-108-8TAE1-GO4,900ohms,200DPI,4",24V,KC66,
4 Lock Hole
1
RT700/RT700W
09
219-124240-012
TPH,KRB-106-12TAE1-GO,1500ohms,+/-3%,300DPI,4",24
V,KC66
1
RT730
10
220-325705-204
STEPPING,MOTOR,T4216R07,7.5°,57mm,24V,Bipolar
1
RT700/ RT700W
11
220-314205-20B
STEPPING,MOTOR,KV4239-N3B003,3.75°,42mm,24V,Bip
olar
1
RT700i/
RT700iW/RT700x/
RT700i+
12
227-100035-000
GND WIRE,500mm(Motor300mm),UL1007,18AWG,Green
1
13
227-110011-040
HOUSING,PHD2.0-2*5P,400mm,1061#28AWG
1
RT700/RT700W/R
T700x
14
227-116018-040
PH2.0-16P/2.0-2*15P,500mm,UL1007,#26 & UL1095,#28
1
15
700-063301-001
Bottom base cover,Black 6u 2x,PT1000
1
RT700/RT700i
16
700-081500-001
Ribbon Supply Rewind Holder,RT200
1
17
700-081800-011
Sensor Case,RT200,RT700
1
18
700-081900-001
Sensor Case Lock Plate,RT200
1
19
700-082905-011
Push Button Enter,Black,RT200
1
20
700-083005-011
Push Button Power,Black,RT200
1
21
700-083700-001
Bushing Lock,RT200
2
22
700-084105-011
Push Button Arrow,Black,RT200
1
RT700i/RT700iW/
RT700i+

Godex RT700 SERIES Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Max Print Speed	5 ips
Max Print Length	1727 mm (68")
Processor	32-bit RISC
Interface	USB, Serial, Ethernet
Media Type	Continuous, Die-cut, Fan-fold
Media Width	25.4 mm - 118 mm (1" - 4.64")
Media Thickness	0.06 mm - 0.25 mm
Media Roll Diameter	127 mm (5")
Ribbon Width	30 mm - 110 mm (1.18" - 4.33")
Power	100-240V AC, 50/60Hz
Dimensions	285 mm (L) x 210 mm (W) x 171 mm (H)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
