Godex RT800i Series User Manual

APPENDIX─PRODUCT SPENIFICATIONS
Model
RT833i
Print Method
Thermal Transfer / Direct Thermal
Resolution
300 dpi (12 dots/mm)
Print Speed
5 IPS (127 mm/s)
Print Width
105.7 mm (4.16”)
Print Length
Min. 0.16” (4 mm)**;
Max. 30” (762 mm)
Processor
32 bit RISC CPU
Memory
Flash
128 MB Flash (60 MB for user storage)
SDRAM
32 MB
Sensor Type
Adjustable reflective sensor (full range). Fixed transmissive sensor, central aligned
Media
Types
Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width
Min. 0.79“ (20.0mm)─Max. 4.64“(118 mm)
Thickness
Min. 0.003" (0.076 mm) ─Max. 0.008”(0.20mm)
Label Roll Diameter
Max. 5” (127 mm)
Core Diameter
1” (25.4mm), 1.5”(38.1mm)
Ribbon
Types
Wax, wax / resin, resin
Length
984.25’ (300 m)
Width
1.18” Min. - 4.33” (30 mm - 110 mm) Max.
Ribbon Roll Diameter
2.67” (68mm)
Core Diameter
1” (25.4 mm)
Printer Language
EZPL, GEPL, GZPL auto switch
Software
Label Design software
GoLabel (for EZPL only)
Driver
Windows 2000, XP, Vista, Windows 7, 8.1 and 10 , Windows Server 2003 & 2008、 MAC、 Linux
SDK
Win CE, .NET, Andriod, Windows Mobile, Windows 2000 / XP / VISTA / Windows 7 / Windows 8.1 / Windows 10
Resident Fonts
Bitmap Fonts
6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
TTF Fonts
TTF Fonts (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Download Fonts
Bitmap Fonts
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian Fonts
16x16, 24x24. Traditional Chinese (BIG-5), Simplified Chinese(GB2312), Japanese (S-JIS), Korean (KS-X1001)
90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
TTF Fonts
TTF Fonts (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Barcodes
1-D Bar codes
China Postal Code, Codabar, Code 11, Code 32,Code 39, Code 93, Code 128 (subset A, B, C), EAN-8/EAN-13 (with 2 & 5
digits extension), EAN 128, FIM, German Post Code, GS1 DataBar, HIBC, Industrial 2 of 5 , Interleaved 2-of-5 (I 2 of 5),
Interleaved 2-of-5 with Shipping Bearer Bars, ISBT-128, ITF 14, Japanese Postnet, Logmars, MSI, Postnet, Plessey, Planet 11
& 13 digit, RPS 128, Standard 2 of 5, Telepen, Matrix 2 of 5, UPC-A/UPC-E (with 2 or 5 digit extension), UCC/EAN-128 K-Mart
andRandom Weight
2-D Bar codes
Aztec code, Code 49,Codablock F , Datamatrix code, MaxiCode, Micro PDF417, Micro QR code, PDF417,QR code, TLC
39, GS1 Composite
Code Pages
CODEPAGE 437, 737,850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869,
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8 UTF16BE UTF16LE
Graphics
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software Serial port:
Interfaces
Serial port: RS-232 (DB-9)
USB Device port (B-Type)
IEEE 802.3 10/100 Base-Tx Ethernet port (RJ-45)
USB Host (A-Type)
Parallel Port (Mini-Centronics)
Control Panel
Backlight 3.2" Touch Screen LCD
Calibration button
Control Key : FEED
Power on/standby button
Power
Switching power 100-240VAC, 50-60Hz input
Environment
Operation Temperature
41°F to 104°F (5°C to 40°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Humidity
Operation
25-85%，non-condensing
Storage
10-90%，non-condensing
Agency Approvals
CE(EMC)、FCC Class A、CB、UL、cUL
(The safety certification marks may be different depending on sales regions.)
Dimension
Length
11.0” (280 mm)
Height
7.7” (195 mm)
Width
8.3” (210 mm)
Weight
5.9 lbs (2.7 Kg) ,excluding consumables
Options
Label dispenser
Cutter
External label unwind Stand
External label rewinder
Bluetooth (dealer install)
Wireless LAN (IEEE 802.11 b/g/n)
Real Time Clock(RTC)
