5.2 Installing the Label Dispenser
The Overview of the Label Dispenser
Preparation Steps
Please see the Section 5.1 Preparation Steps to complete the preparation steps before installing the label
Dispenser.
Installing the Label Dispenser
1. Removed the front panel.
2. Press the catches on the left and right sides of the platen downwards and then pass the connection cable
through the slot of the printer.
Note
* A label liner thickness of 0.06 mm ± 10% and a weight of 65 g/m2 ± 6% are recommended.
* The label dispenser will take labels up to a max. width of 118 mm.
* When using the label dispenser, set the stop position (printer command ^E) to 13.
To Next Page
