Godex RT800i Series User Manual

APPENDIX─Communication Port Specifications
Pinout Description
 USB Port
Connector Type：Type B
Pin NO.
1
2
3
4
NV
D-
D+
GND
 Serial Port
Default Settings : Baud rate 9600, no parity, 8 data bit, 1 stop bit, XON/XOFF
Protocal and RTS/CTS
RS232 Housing (9-pin to 9-pin)
Pin NO.
1
2
3
4
5
6
7
8
9
Type
+5V,
Max 500 mA
TXD
RXD
N/C
GND
RTS
CTS
RTS
N/C
DB9 Plug
-
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI
DB9 Socket
 Ethernet Port
Type : RJ45
Pin NO.
1
2
3
4
5
6
7
8
TX+
TX-
RX+
NC
NC
RX-
NC
NC
 USB Host
Connector Type : Type A
Pin NO.
1
2
3
4
VBUS
D-
D+
GND
 Parallel Port
Type：Centronics Female
Pin
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
BUZY
SELECT
ACK
FAULTN
LPT
PERR
DATA0
DATA1
DATA2
DATA3
DATA4
DATA5
DATA6
DATA7
LPT
INTN
STROB
SELIN
AUTO
NC
Pin
NO.
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
5V
Note
* Serial port total output can not exceed the maximum current of 500mA
USB Port
Serial Port
Ethernet Port
USB Host
Parallel Port
Power
Jack
