Godex RT800i Series User Manual

2.2 Loading the Ribbon
A New Ribbon Module Installation
1. Attach the ribbon to the empty ribbon core with the adhesive strip at the end of the ribbon.
2. Insert the ribbon hub into empty ribbon core and new ribbon. Wind the ribbon around the empty ribbon
core for 2 to 3 circles.
3. A ribbon module is assembled as below.
A NEW RIBBON
EMPTY RIBBON CORE
RIBBON HUB
Stick on empty ribbon core
Insert the ribbon hub
Wind the ribbon around the core
A NEW RIBBON MODULE
RIBBON SUPPLY
RIBBON REWIND
