REAR PANEL
REAR PANEL OVERVIEW
IS-1000 features a wide selection of connections to offer the best versatility and become the core of a real High-End system
that will deliver audio in true audiophile quality:
- 7 digital inputs (PCM up to 24bit/192kHz & DSD 64 )
- 3 analogue inputs (1 XLR balanced and 2 RCA unbalanced)
- 4 analogue outputs (variable and fixed)
6
7
8
9
10
11
12
13
15
14
16
17
18
19
20
21
22
23
LED
1 2
3
4
5
1
2
3
XLR balanced
ANALOG INPUT
RCA 1 unbalanced (LINE or PHONO)
RCA 2 unbalanced (LINE or AV)
4
5
RCA unbalanced VARIABLE
RCA unbalanced FIXED
ANALOG OUTPUT
DIGITAL INPUT
6
9
10
11
12
15
16
RF IN (Wi-Fi aerial)
TOS link 1
TOS link 2
TOS link 3
COAX
Ethernet
USB type A (USB flash memories)
7
8
13
mini USB (Firmware update)
Firmware Reset only for service
Wi-Fi Reset (to connect to your Wi-Fi)
18
22
23
LINK sync trigger
Serial Number
GND (PHONO)
OTHERS
14
Blue light LED
17
19
Master Switch ON/OFF
AC plug IEC standard
POWER
20
21
SPEAKER OUT left
SPEAKER OUT right
7
To Next Page
