SCENARIO 2: POWER TO CONTROL PANEL, BUT SCOOTER WILL NOT RUN.
You insert the key into the key switch. The status LED indicates power (but no BEEP code) and the battery condition
meter indicates a full charge. You push the paddle and the scooter does not move.
Less than 1 ohm?
Open?
Less than 1ohm? Open?
Less than 1ohm? Open?
Remove the battery pack
from the scooter.
Measure resistance across
BAT1 and BAT2 located on the
battery box.
Replace the controller.
Remove the cover from the controller.
Disconnect the main harness (MH1) from the controller (CN7).
Measure resistance across pin 7 (red wire) on MH1and pin 4 (red wire) on MH2.
Replace the top dashboard.
Replace the intermediate
charger harness (ICH).
Open the front control panel.
Disconnect main harness (MH2) from the top dashboard (TD1).
With the key still in the key switch, measure resistance across pin 4
(red wire) and pin 8 (white wire) on TD1.
Replace the main harness.
