BEEP CODE #2 – LOW BATTERY VOLTAGE
The battery needs charging or there is a bad connection to the battery.
Won’t charge?
0VDC? 16-24VDC or
battery voltage
Open? Less than 1 ohm?
BEEP CODE #3 - HIGH BATTERY VOLTAGE
An excessive voltage has been applied to the S-drive. This is usually caused by a poor battery connection.
Loose or poor connection?
Good connections?
NOTE: The error may only be present when going down hill and power goes back to the batteries.
Charge the batteries. Open battery box. Check connections.
Measure voltage on BAT- of one battery and
BAT+ on the other battery.
Take measurement at terminals connected to
the circuit breaker (CB3 and CB6).
Replace the intermediate
charger harness (ICH).
Measure resistance across the circuit
breaker terminals (CB1 and CB2).
Replace the circuit breaker.
Check continuity between CB3
and CB4 (red wire) and between
CB5 and CB6 (black wire).
Replace as necessary.
Check the battery connections.
1. Prop up the scooter, so that the drive wheels are off the ground.
2. Insert the key into the key switch and turn it to the “ON” position.
3. Keep the paddle on the throttle pot depressed, to allow the battery
level to drop.
**Do not allow the battery meter to drop into the “RED” area.
Clean and tighten
connections as
necessary.
Check the battery charger.
**Make sure it is an APPROVED charger.
Model: HP1202B
