BEEP CODE #5 – SOLENOID BRAKE TRIP
The parking brake has a bad connection.
Outside that range? Less than 80 ohms
but not shorted?
Yes? No?
Yes? No?
Outside that range?
Less than 80 ohm
but not shorted?
Less than 80 ohms
but not shorted? Out of range?
No?
Yes?
Less than 80 ohms but not shorted?
Outside that range?
Make sure the scooter is in the drive mode.
Check the parking brake and motor connections.
Make sure all system connections are secure.
Separate front and rear halves of the scooter.
Measure resistance across IMH3 (orange wire) and IMH5 (blue wire) on the intermediate
motor harness located on the rear frame.
Make sure the scooter is
completely reassembled.
Turn the scooter onto its side.
Remove the controller cover.
Unplug the brake harness (PH10) from the controller.
Are the pins on PH10 seated correctly?
Reseat the pins, reconnect
the power harness to the
controller, and try to run
the scooter.
Measure resistance across
pin 1 (orange wire) and pin
2 (blue wire) on the brake
harness (PH10).
Replace the controller.
Replace the
power harness.
Unplug the intermediate motor harness (IMH1)
from the motor harness (MT1).
Are the pins on the connectors seated correctly?
Reseat the pins, reconnect
IMH1 to MT1, and try to
run the scooter.
Measure resistance across
pin 3 (orange wire) and pin
4 (blue wire) on the motor
harness (MT1).
Replace the
intermediate motor
harness (IMH).
Unplug the motor brake (MB1) from the motor harness (MT2).
Are the pins on the connectors seated correctly?
Reseat the pins,
reconnect MB1 to
MT2, and try to run
the scooter.
Measure resistance across pin 1 and pin 2 on MB1.
Replace the drive train.
Replace the park brake.
