BEEP CODE #6 – THROTTLE TRIP (OUT OF NEUTRAL)
A throttle trip is indicated. Make sure the throttle is in the neutral position before switching on the scooter.
Yes? No?
Yes? No?
BEEP CODE #7 – THROTTLE TRIP/SPEED CONTROL FAULT (VOLTAGE ERROR).
A throttle trip is indicated. This fault indicates a problem with the throttle control or speed control.
Out of range? Approximately 25VDC?
Yes? No? Approximately Out of range?
2.7k ohms?
No? Yes?
Remove the key from the key switch.
Make sure the throttle pot is not obstructed and it can return to the neutral (center) position.
Move the throttle pot forward and then reverse. Make sure that it is not obstructed.
Does it spring back to neutral the neutral position?
Check for obstruction.
Replace if there are no obstructions.
Insert the key into the key switch.
Does the code return?
OK
Go to BEEP CODE # 7
to test the throttle pot.
Make sure the batteries are fully charged.
Remove the battery pack.
Remove the battery pack lid.
Reinstall the battery pack onto the scooter frame.
Open the front control panel.
Insert the key into the key switch.
Insert the positive lead (red) from the multimeter into the back of pin 6 (yellow wire) on the main harness (MH2).
Connect the negative lead (black) from the multimeter to BAT-. Use the BAT- terminal that is connected to ICH2.
Measure the voltage.
Measure resistance across pin 2
(yellow wire) and pin 3 (orange wire)
on the throttle pot connector.
Disconnect the throttle pot from the top dashboard.
Check the top dashboard.
Is it discolored or dama
ed?
Replace the top dashboard.
Replace the throttle pot. Replace the top dashboard.
Are the pins on the connectors seated correctly?
Reseat the pins,
reconnect the throttle pot
to the top dashboard, and
try to run the scooter.
