Buzzaround_SG_REVA_040711
38
Front Frame Assembly (SB05E103)
ITEM PART NO. DESCRIPTION QTY
01 SA2P002A Handle joint seat 1
02 SB2P505A Rubber sheath 1
03 3000406072 Flat washer Ø6.2 * Ø13 * 1.5 (Black) 2
04 3003106019 Spring washer Ø6 (black) 2
05 3100206012 Cap-shaped nut M6 (Black) 2
06 3090400010 Pearl bowl nut 1 "-24UNF (Black) 1
07 3110306012 Hexagon socket head screw M6 * 35L (black zinc-plated) 2
08 3090400020 Pearl bowl washer Black 1
09 3090400030 On the bearing holder Black 1
10 3090400040 Pearl bowl bearing 2
11 3090400050 The bead bowl Ø30 (black) 1
12 SB2P203A Small compression spring Ø1 * Ø12 * 23.7L 1
13 3002330010 Leading labels 22 30 * 1
14 SB2A201A Front wheel knob 1
15 3110305019 Hexagon socket head screw M5 * 12L 1
16 3090400060 Under the bead bowl Ø30 (black) 1
17 3090400070 Under the bearing holder Ø37 (black) 1
18 3000925010 Square tube plug 25 * 25 * 1.5 (Black) 2
19 SB3A201A Front wheel fork group Electric black 1
20 SB2P202A Turn off limit Ø6 * 29L 1
21 SB05E203 Wheel, Assembly Front and Rear Complete for Buzz GB106 January 2010 1
22 3000408011 Flat washer Ø8.4 * Ø16 * 1.6 (white zinc plated) 2
