Buzzaround_SG_REVA_040711
39
23 SB2P209A Stud M8 * 88L 1
24 3003108019 Spring washer Ø8 (black) 2
25 3100208012 Cap-shaped nut M8 2
26 3111704011 Cross trough with meson drilling screw ST4.2 * 13L (white zinc plated) 4
27 3002330030 Barcode sticker 30 * 13 1
28 SB3P113A Bottom Panel 1
29 3100304011 Nylon nut M4 (white zinc plated) 2
30 3000404051 Flat washer Ø4.3 * Ø9 * 0.8 (white zinc plated) 2
31 3051600010 Controller S-DRIVE 1
32 SB3A101A Front Frame Section Electric black 1
33 SB3P118A T-bolt compression spring White zinc-plated 1
34 SB3P114A T-Bolt White zinc-plated 1
35 3000602029 Spring pin (straight groove) Ø2.5 * 14L (black) 1
36 3111005051 Cross Countersunk head screws M5 * 16L (white zinc plated) 2
37 SB3E604A Block electrode 1
38 3100305011 Nylon nut M5 (white zinc plated) 2
39 SB3P117A Reset torsion spring White zinc-plated 1
40 3000410011 Flat washer Ø10 (white zinc plated) 1
41 3100110031 Hexagon nut M10 (white zinc plated) 1
42 SB3A104A Spin lock handle set White zinc-plated 1
43 3111504027 Set Screw M4 * 6 (black) 1
44 3100310011 Nylon nut M10 (white zinc plated) 1
45 SA2P423A Pipe plug Ø25.4 * 2 (Black) 2
Tiller Assembly (SB05E201)
ITEM PART NO. DESCRIPTION QTY
01 SB05E202 The combination T 1
02 SB3P521A Basket holder 1
03 SB3P119A Basket hook 1
04 3111005302 Cross Countersunk head screws M5 * 30 (black zinc-plated) 4
05 SB3A503A Basket holder 1
To Next Page
