golmar Art 7/G2+ - Configuration of Video Sources and System Roles; Function Activation and Control

29
SPECIAL CODES
Continued from previous page.
Video sources available on a monitor (configure only on the master monitor).
Visible Not isiblev Factory setting
Door panel 1 0111 0110 0111
Door panel 2 0121 0120 0120
Door panel 3 0131 0130 0130
Door panel 4 0151 0150 0150
C m ra 1 0141 0140 0140a e
C m ra 2 0181 0180 0180a e
C m ra 3 0171 0170 0170a e
C m ra 4 0191 0190 0190a e
Important: Available with EL632-G2 + SE video module with 'V03' or later.
General door panels installations, available with EL632-G2+ SE with ’V04' or later.
To define whether the monitor is master, slave 1, slave 2 or slave 3
:
Master lave lave lave Factory settingS 1 S 2 S 3
0550 0551 0552 0553 0550 (master)
Automatic door opening upon reception of a call on a monitor (configure only on the master monitor).
Activated Deactivated Factory setting
0441 0440 0440
Activate/deactivate the ('power on indicator' notification icon) and (LEDs of the hidden buttons above raised
dots / for the visually impaired) on a monitor.
te teActiva Deactiva Factory setting
0471 0470 0471 (activated)
Do not show the image on the monitor when receiving a call from the door panel when the monitor is in 'Do not
disturb' mode.
ShowDo not show Factory setting
0481 0480 0480 (show image)
Activate/ deactivate the in all monitors (building).images recording
Activate Deactivate Factory setting
0531 0530 0531 ( )activated
Enable/ disable the icon of the main menu in all monitors (building).
Enable Disable
Factory setting
0541 0540 0541 ( )enable
LED lights for night viewing (Door panel 1) during a call or communication process. (Configure only on the
master monitor).
Automatic OFFAlways ON Always Factory setting
0450 0451 0452 0450 (automatic).
Activation times of the outputs (Door panel 1). (Configure only on the master monitor).
Factory setting
Relay 1 From to0200 (0,5s) 0219 (10s) 0205 (3s)
Rel 0300 (0,5s) 0319 (10s) 0305 (3s)ay 2 From to
Configuration of the remote activation button (Door panel 1). (Configure only on the master monitor).Relay1
Factory setting
Delay From to0400 (0,5s) 0419 (10s) 0403 (2s)
Configuration of the remote activation button (Door panel 1). (Configure only on the master monitor).Relay2
Factory setting
Delay From 5 to 5 50 00 (0,5s) 0 19 (10s) 0 03 (2s)
ART 7T/G2+ MONITOR
Continued overleaf
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
*
( )
