3
SYSTEM OPERATION
RECOMMENDATIONS
- The wiring must run at least 40cm away from any other wiring.
- Always disconnect the power supply before making modifications to the device.
- Preferably use a Golmar cableRAP-GTWIN/HF (2x1mm²).
-Always follow the instructions contained in this manual.
- Check all connections before starting the device.
- The installation and handling of these devices must be carried out by authorised personnel.
SOU S5110/ART 7 VIDE ENTL O DOOR RY SYSTEM KIT
In systems with two access doors, the other door panel automatically disconnects; if another visitor attempts to call, a
number of telephone tones will indicate that the system is busy and LED on the door panel will illuminate.
Upon receiving the call, the image will appear on the screen of the master monitor (and slave 1, if it exists) without the
visitor knowing and icon displayed on the screen will blink green. To view the image from slave monitors 2 or 3,
press one of the hidden buttons (located above the raised dots for the visually impaired) of the monitor to display the
image. If the call is not answered within 45 seconds, door panel LED will turn off and the system will become free.
To open door or activate auxiliary output of the door panel, press the hidden button below the corresponding icon
displayed on the screen. A single press activates the lock release or auxiliary output for 3 seconds
, and LED on the door panel illuminates.
(with the possibility of
setting it to between 0.5 and 10 seconds see pp. 32-34),
Detailed operation of the monitor is described on pp. 11-24.
To make a call, the visitor needs to press the button for the apartment, an audible tone indicates that the call is being
made and LED on the door panel illuminates. At this moment, the apartment's monitor(s) receive(s) the call. If the
visitor presses the button for another apartment by mistake, the call can be cancelled by pressing the button for the
correct apartment.
The owner of the apartment can activate the lock release by holding the proximity key over the reader. If the proximity
key is held for three seconds, the auxiliary relay output will be activated.
To establish communication, press the hidden button below off-the-hook icon shown on the screen. Door panel
LED will illuminate. Communication will last for 90 seconds or until the hidden button below on-the-hook icon
shown on the screen is pressed. When communication has ended, door panel LED will turn off and the
system will become free.
