TELEPHONE INSTALLATION
58
D
escrip T- 40 Unotion of telephone.5 SE
a.
b.
c.
d.
e.
f.
g.
Handset
.Sound diffusion unit
.Microphone
.Fixing hole
Phone cord connector.
Function button
.Hang up button
In order to connect the phone and to fix it to the wall,
it is necessary to open it.
Put a flat screwdriver in the proper openings as
shown in the picture and prise them open.
Pass the cables through the proper hole and connect them to the
terminal block, as shown in installation diagrams. Close the phone as
shown in the picture, then connect the handset by means of the phone
cord and hang it up.
TELEPHONE DESCRIPTION
57
door bell push button input.
positive, .negative (18Vdc)
digital communication.
audio communication.
HZ-
T
e .rminal connector description
AD
+
_
a
d
c
e
b
f
g
e
F
i .x the telephone to the wall
F
unction button.
When the handset is lifted, it is possible to make a call to master porter's
exchange.
When a call is received or during communication, it enables the lock release.
HZ- :
– , + :
D :
A :
Do not install the device near heat sources, in places
with dust or fumes. The phone can be fixed in a universal
box or directly to the wall. To fix it directly to the wall,
drill two 6mm holes in the position shown in the picture,
by means of 6mm s and screws.screw Ø3,5 x 25mm
