16
Anti-reverse function connection
If ETC system (connected with grid-tied inverters) requires anti-reverse function, it is operable but
please note:
1. This diagram is only for installation where there is exporting power limit function requirement.
2. For anti-reverse function, it can be set on Screen→Settings→Operation Mode→Self-Use→Power
limit.
3. This diagram will only applies if grid-tied inverter has anti-reverse function build-in. And the
power limitation value can be set on grid-tied inverter.
4. When using anti-reverse function, it would buy about 500W from the grid.
ETC series inverter complies with IEC 62109-2 13.9. Fault indicator LED on the inverter cover will light
up and the system will email the fault information to customer.
2.4 Earth Fault Alarm Connection
Declaration for back-up overload protection
Inverter will restart itself if overload protection triggers. The preparation time for restarting will be
longer and longer (max one hour) if overload protection repeats. Take following steps to restart
inverter immediately.
• Decrease back-up load power within max limitation
Smart Meter & CT Connection
• Make sure AC cable is totally isolated from AC power before connecting
Smart Meter & CT.
• For the detailed operation steps of connecting CT, please refer to
"GM3000C Electric Meter Quick Installation Instructions".
