05
1
2
3
4
5
6
7
9
8
15
11
12
13
14
16
17
10
GW50K-ETC
(1) Monitoring Unit (EMS1000)
(3) DC-DC Conversion Module (GW50K-DCM)
(5) ON/OFF Grid Switching Module (GW100K-STS)
(7) Load Circuit Breaker (LOAD)
(9) Battery Circuit Breaker（BAT)
(11) Heat Dissipation Hole
(13) PV DC Input Terminal (MPPT)
(15) Load Terminal (LOAD)
(17) AC Output Terminal (GRID)
(2) MPPT Module (GW50K-PVM)
(4) Power Conversion System Module
(GW50K-BTM)
(6) AC Output Circuit Breaker (GRID)
(8) Emergency Stop Button
(10) MPPT DC Input Circuit Breaker (MPPT)
(12) Communication Cable Port
(14) Battery DC Terminal (BAT)
(16) PE Terminal
