Goodwe Lynx Home F Plus+ Series User Manual

43
09 Parameters
User Manual V1.9-2023-04-30
Technical Parameters LX F6.6-H LX F9.8-H LX F13.1-H LX F16.4-H
Usable Energy(kWh)*
1
6.55 9.83 13.1 16.38
Battery Module LX F3.3-H: 38.4V 3.27kWh
Number of Modules 2 3 4 5
Cell Type LFP(LiFePO4)
Cell Conguration 64S1P 96S1P 128S1P 160S1P
Nominal Voltage (V) 204.8 307.2 409.6 512
Operating Voltage Range (V) 182.4~230.4 273.6~345.6 364.8~460.8 456~576
Nominal Dis-/Charge Current
(A)
*2
25
Nominal Power (kW)
*2
5.12 7.68 10.24 12.8
Short-Circuit Current 2.62kA @ 1.62ms
Operating Temperature Range
(℃)
Charge: 0 ~ +50; Discharge: -20 ~ +50
Relative Humidity 0~95%
Max. Operating Altitude (m) 2000
Communication CAN
Weight (kg) 115 158 201 244
Dimensions (W×H×D mm)
600×610×380 600×765×380 600×920×380 600×1075×380
Ingress Protection Rating IP55
Storage Temperature (℃) -20 ~ +45 (≤ One Month); 0 ~ +35 (≤ One Year)
Mounting Method Grounded
Round-trip Eciency 96.40%
Cycle Life
*3
≥3500 @1C/1C
Standard and
Certication
Safety IEC62619, IEC 62040, VDE2510-50, CEC,CE
EMC CE, RCM
Transportation UN38.3
*1: Test conditions, 100% DOD, 0.2℃ charge & discharge at +25±2 °C for battery system at
beginning life. System Usable Energy may vary with dierent Inverter.
*2: Nominal Dis-/Charge Current and power derating will occur related to Temperature and
SOC.
*3: Based on 2.5~3.65V voltage rang @25±2℃ of Cell under 1C/1C test condition and 80% EOL.
