Goodwe Lynx Home F Plus+ Series User Manual

09
03 Product IntroductionUser Manual V1.9-2023-04-30
No. Parts
1 PCU
2, 3, 4, 5, 6 Battery
7 Base
No. Parts
1 Ventilation valve
2 Rectangular connector
No. Parts
1 Rectangular connector
2 Grounding point
NOTICE
• Ensure that the PCU is installed
above the battery modules. Do
not install any battery modules
above the PCU.
• This manual will show you
the installation and electrical
connection of 5 battery modules.
3.3 Appearance
Battery system appearance
Battery appearance
Base appearance
