Version: V1.2 17
2.3 Memory installation
The motherboard supports 8 DDR4 channels, each channel supports 1 DIMM. 2 CPUs support 16 DDR4 slots (when
only one memory is inserted, the slot in the red box in the figure below is preferred).
Note: In order to make the system more stable, it is recommended to use AMD compatibility list memory.
The location is shown in the figure below:
Figure 2-5
Note that the notches on the memory line up with the notches on the DIMM slots, and snap each DIMM module
vertically into place to prevent incorrect installation.
Figure 2-6
