Gooxi G2DERO-B User Manual

Version: V1.2 70
Chapter 4 RAID Setup Instructions
4.1 LSI 9361-8i configuring RAID
4.1.1 Configuring RAID in UEFI boot mode

Enter the RAID card configuration interface
a) During server startup, press Delete/Esc as prompted to enter the BIOS Setup interface.
b) Select Advanced>AVAGO MegaRAID<AVAGO MegaRAID SAS 91311-8i>Configuration Utility and press Enter.
c) Enter the interface shown in Figure 4-1, and five types of configuration tasks are displayed on the interface (see
Table 1-33 for related descriptions).
Figure 4-1
 Table 1-33 Parameter description
Options
Summary
Configuration
Management
Select Configuration Management to perform tasks such as creating
logical disks, viewing disk group properties, viewing hot spare
information, and clearing configurations.
Controller
Management
Select Controller Management to view and manage controller properties
and perform tasks such as clearing controller events, scheduling and
running controller events, and running patrol reads.
Virtual Drive
Management
Select Logical Disk Management to perform tasks such as viewing
logical disk properties, locating logical disks, and running consistency
checks.
Drive Management
Select Disk Management to view physical disk properties and perform
