Version: V1.2 71
tasks such as locating a disk, initializing a disk, and rebuilding after a
failed disk.
Select a hardware component to view supercap properties, manage
supercapacitors and manage peripheral components.
Table 1-33
ļ Common tasks
Switch disk mode:
The RAID card supports switching between the following three disk modes.
1. Unconfigured Good: Indicates that the physical disk is normal and can be used to configure RAID or hot spare disk.
2. Unconfigured Bad: Indicates that there is residual RAID information on the physical disk and needs to be cleared
manually.
3. JBOD: Just a Bunch Of Disks, which only connects disks together for capacity expansion, but does not have the
RAID function.
Here is an example of switching from Unconfigured Good mode to Unconfigured Bad mode.
a) As shown in Figure 4-2, select Drive Management on the RAID card configuration interface and press Enter.
Figure 4-2
b) Enter the interface shown in Figure 4-3, select the disk to be configured, and press Enter.
To Next Page
