GPRINTER S-4231 - Page 8

Internal
<Picture 4>
The bottom
Note: Picture showing printer port is for s-4232,S-4332.
Label paper fixing stand
Ribbon take-up hub
Push button for thermal
print head open
Top cover
Label paper supply hub
Bottom cover with DIP switch
RS-232C serial port
Ethernet port
Label entrance from
external holder
USB port
Parallel port
Power port
