Graco 24M398 - Remote Manifold Carriage 262522 and 24 Z934

Component Identification
10 3A0590R
Remote Manifold Carriage 262522 and 24Z934
Ref. Description
BC Remote Manifold Carriage
BD Long Fasteners (shipped loose)
BE Heater Block
WLD
%(
%&
%'
%'
%&
Remote Manifold Carriage
with Heater Block 24Z934
Remote Manifold Carriage
FIG. 2: Remote Manifold Heater Block Component Identification
