Ref. Description
AA “A” Material Inlet
AB “B” Material Inlet
AE Dual Shutoff Handle
AF Hardener Restrictor Adjustment
AV Fasteners
BC Remote Manifold Carriage
DB “B” Side Solvent Line
DC “B” Side Solvent Shutoff
DD “A” Side Solvent Line
DE “A” Side Solvent Shutoff
DF Solvent Inlet Tree
DG Primary Mix Housing
DH Static Mixing Element (not shown, inside DH)
DJ Fluid Whip Hose (shipped loose)
DK Adapter Fitting (shipped loose)
DL XHF Gun (shipped loose)
