Graco 24M398 - Remote Recirculation Kit 420033

Component Identification
3A0590R 11
Remote Recirculation Kit 420033
Ref. Description
CA Recirculation Manifold “A” Inlet
CB Recirculation Manifold “B” Inlet
CD Recirculation Hose Shut-Off Valve
CE Remote Recirculation Handle
CF Remote Recirculation Tube
CG Remote Recirculation Hose
CH Bushing (shipped loose)
CJ Adapter Fitting (shipped loose)
CK “A” Fitting End
CL “B” Fitting End
CR Remote “B” Recirculation Port
CS Remote “A” Recirculation Port
WLD
&)
&'
&*
&+
&-
&6
&.
&%
&$
&5
&(
&/
FIG. 3: Remote Recirculation Kit Component Identification
