Component Identification
3A0590R 13
Typical Installation
Ref. Description
CSolvent Pump
D Recirculation Lines
E Recirculation Handles
F Recirculation Manifold
G Solvent Supply Hose
H Solvent Hose Extension
J Primary Mixer Housing
K Fluid Whip Hose
L Airless Spray Gun
M Static Mixing Element (not shown inside J or P)
N Fluid Mix Hose
WLD
6
5
+
%&
5
$'
)
(
'
'
$*
$(
*
6
&
&)
&)
&(
&*
&(
&5
&%
-0
-0
1
30
.
/
&6
A
B
A
B
&+
&-
Ref. Description
P Clean-up Mixer Tube
R “B” Recirculation Hose
S “A” Recirculation Hose
AD Mix Manifold
AE Dual Shutoff Handle
AG Solvent Shutoff Handle
BC Remote Carriage
CE Remote Recirculation Handle
CF Remote Recirculation Tube
CR Remote “B” Recirculation Port
CS Remote “A” Recirculation Port
FIG. 5: Typical Installation
