Related Manuals
3A0590R 3
Related Manuals
Manuals are available at www.graco.com
Component Manuals in English:
Model Information
Accessories
Manual Description
3A0420
XP Proportioner, Instructions-Parts
3A0421
Ratio Check Kit, Instructions-Parts
306861
Ball Valves, Check Valves, and Swivels, Instructions-Parts
339361
High Pressure Hose and Accessories Brochure
3A4381
XP-hf Proportioner, Instructions-Parts
3A6283
XPs-hf Proportioner, Instructions-Parts
3A5313
Xtreme-Wrap Water Heated Hose
3A7524
Xtreme-Wrap Electric Heated Hose
Model Mix Manifold
Maximum
Working Pressure
(A and B Materials)
Maximum Solvent
Pressure
Maximum Fluid
Temperature
Approvals
262807
Standard
XP Mix
Manifold
7250 psi
(50 MPa, 500 bar)
5000 psi
(34.5 MPa, 345 bar)
160 °F
(71 °C)
24M398
Quickset Mix
Manifold
7250 psi
(50 MPa, 500 bar)
5000 psi
(34.5 MPa, 345 bar)
160 °F
(71 °C)
II 2G Ex h IIC T5 Gb
II 2G Ex h IIC T5 Gb
Model Description
Maximum Working
Pressure
Maximum Fluid
Temperature
For use with
(items sold separately)
262522
Remote Mix Manifold
Carriage
262807
with Heated Hose
24Z934
Remote Manifold Carriage
(with heater block)
262807 and Water Heated
Hose System
420033 Remote Recirculation Kit
7250 psi
(50 MPa, 500 bar)
160 °F
(71 °C)
262807 or 24M398 with
Heated Hose
