Gun Placement
16 3A4587D Operation, Repair, Parts
b. Left-side gun position: Place gun and related
hardware on left-hand side.
4. For Curb Position, place gun at 45° angle.
5. For Gun Arc Spray Position, place gun at rear of
striper. Rear position improves arc quality.
NOTE: Verify that the gun can still be triggered and that
the trigger lock can still be engaged after installation.
Make adjustments if necessary.
ti30098
ti30099a
