Technical Data
3A4587D Operation, Repair, Parts 43
Technical Data
LineLazer 3400 (Model 25M224)
US Metric
Honda GX120 engine
SAE J1995 @ 3600 rpm 4.0 Horsepower
Maximum working pressure 3300 psi 22.8 MPa, 228 bar
Maximum delivery 0.75 gpm 2.84 lpm
Maximum tip size 1 gun with 0.027 in. tip
Inlet paint strainer 12 mesh (893 micron) stainless steel screen, reusable
Outlet paint strainer 60 mesh (250 micron) stainless steel screen, reusable
Pump inlet size 1.0 in. diameter
Fluid outlet size 0.25 in. diameter
Noise Level
Sound power, per ISO 3741 95.4 dBA
Sound pressure, per ISO 3741 91.0 dBA
Vibration, per ISO 5349
Left-hand
260 in/s
2
6.60 m/s
2
Right-hand
225 in/s
2
5.72 m/s
2
Wetted parts stainless steel, PTFE, leather, nylon, zinc-plated and
nickel-plated carbon steel, tungsten carbide, chrome
plating, UHMWPE, acetal, polyethylene,
Dimensions (25M224)
Weight (dry, without packaging) 160.0 lb. 72.5 kg
Height Handles Down 39.4 in. 100.0 cm
Height Handles Up 41.3 in. 104.8 in.
Length Handles Down 66.3 in. 168.4 cm
Length Handles Up 68.0 in. 172.7 cm
Width 26.0 in. 66.0 cm
Gun
Maximum Working Pressure 5000 psi 345, 3.45 (bar, MPa)
Weight (with tip and guard) 18 oz. 510 g
Inlet 1/4 npsm male
Maximum material temperature 120°F 50°C
