Technical Data
3A6584A 19
Technical Data
U.S. Metric
Maximum Working Pressure 3300 psi 227 bar, 22.7 MPa
Fluid Inlet Size 1-5/16-12 un(m) 1-5/16-12 un(m)
Fluid Outlet Size
16Y598, 17H828, 16Y706,
17H829, 17H830
3/8 npt(f) 3/8 npt(f)
17H831 1/2 npt(f) 1/2 npt(f)
Wetted Parts
stainless steel, PTFE, leather, nylon, nickel and zinc-plated carbon steel,
tungsten carbide, chrome plating, fluoroelastomer, acetal, polyethylene
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
CALIFORNIA PROPOSITION 65
