Reassembly
1. Connect
the
clutch housing (2)
to
the adapter plate
(48) using the screws (62) and lockwashers (9). In-
stall
the clutch housing and adapter plate assembly
to
the motor (1), using
the screws (47) and lockwash
-
ers (74)
2.
Install the motor shaft
key (13).
See Fig. 33.
13
1
48
74
47
2
9
62
3
11,16
34
90
12
6
TORQUE
T
O
2.9 – 3.4 N.m
A
Fig.
33
3. Press
the
clamp (3)
onto the motor shaft (A). Main
-
tain
the 50.55 mm (+/– 0.25 mm) dimension shown
in
Fig. 33.
4. To check the dimension, place a rigid, straight steel
bar
(B) across the face of the clutch housing (2). Use
an accurate measuring device to measure the dis-
tance
between the bar and the face of the clamp. Ad
-
just
the clamp as necessary
. T
orque the two screws
(16)
to 13–15 N.m.
5. Install
the
field
(6)
in the clutch housing (2). W
orking
through the slot in the clutch housing, connect the
wires of the harness (90) to the screws (34) in both
places on the field. Pull the plastic caps (C) up and
snap
them over the screws. With
the setscrew holes
in
the field and the clutch housing (2) aligned, tighten
the setscrews (12) oppositely and evenly, to
2.9
to 3.4 N.m. See Fig. 33.
50.55
mm
F
ACE OF
HOUSING
TORQUE TO
13 – 15 N.m
B
16
2
A
Fig.
34
