Service and Repair
12 309869C
15. Grasp the trip rod (40) with pad-
ded pliers. See page 5 for part
numbers.
16. Unscrew the cylinder cap nut (39)
from the trip rod (40).
17. Thread the service nut (A) (not
supplied) onto the top of the trip
rod (40).
CAUTION
Do not damage the plated surface of
the trip rod (40). Damaging the sur-
face of the trip rod can result in
erratic motor operation.
A
To Next Page
