Service and Repair
309869C 13
18. Remove the six hex head screws
(7) holding the air motor plate
identification (46) to the air motor
base (28).
19. Remove the six hex head screws
(7) holding the warning plate (47)
to the air motor base (28).
20. Remove the six hex head cap
screws (9) holding the air motor
cylinder (35) to the air motor base
(28).
