Reassembly
309869C 25
9. Check that the valve actuator (27)
is aligned by the spring clips (26),
and slides easily into them.
Replace the spring clips (26) if
worn or bent.
10. Thread the top valve nuts (24*)
onto the stems of the poppet
valves (32*) until snug.
11. Install the toggle pins (36) in the
trip rod yoke (23).
