ProContractor Series Pump
30 334558D
2. Slowly pull engine starter rope until
pump rod pin hole is aligned with
hydraulic rod hole. Push pin into hole.
Push retaining ring into groove.
3. Fill packing nut with Graco TSL.
ProContractor
Series Pump
Removal
See pump manual 334654 for pump repair.
1. Flush pump.
2. Perform Pressure Relief Procedure,
page 13.
3. Remove suction hose.
4. Remove paint hose fitting and paint
hose from pump fitting.
ti2272
