Technical Data
334558D 63
GH
™
300 Standard Series
US Metric
Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity 1.25 gallons 4.75 liters
Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar
Engine 270 cc (9.0 HP)
Maximum tip size 0.057
Maximum free-flow delivery 3.0 gpm 11.4 l/min
Hose connection 3/8 npsm (m)
Noise (dBa)
Maximum sound pressure 96 dBa
Maximum sound power 110 dBa
Inlet/Outlet Sizes
Fluid inlet size 1 5/16-12 UN-ZA
Fluid outlet size 3/8 npt (f)
Weight 195 lb. 87.8 kg
Width 24 in. 61 cm
Length 48 in. 121.92 cm
Height (Handle extended) 41.0 in. 104.1 cm
Height (Handle retracted) 33.0 in. 83.8 cm
