19307-615
PARTS LIST
Model
231–533
, Series B
Includes items 1–
145
REF
NO. PART NO. DESCRIPTION QTY
1 107–074 BREA
THER, fill cap
1
2 106–114 STRAINER, inlet 1
3
107–053 ELBOW
, pipe, 90
, 1/2 x 3/8 npt
1
4 107–128 TEE, service 1
5 107–050 INSERT,
hose, 1/2 npt(f)
3
7 178–859 HOSE, rubber
, 5” (125 mm)
1
8 102–473 CLAMP,
hose
6
9
210–658 VALVE,
ball 3/8 npt(m)
1
10
165–472
ELBOW
, pipe, 90
, 3/8 npt(f)
1
11
106–039
WHEEL 2
12
106–123
CAPSCREW
, hex hd, 1/2 x 4”
4
13
100–018
LOCKW
ASHER, spring, 1/2”
4
14
100–321
NUT
, hex, 1/2” thread
4
15
188–344
NIPPLE, pipe, reducing, 3/8 x 1/2 npt
1
16 103–475
TEE, pipe, 1/2 npt(f)
1
17 158–491
NIPPLE, short, 1/2 npt
1
18 107–052
FITTING, tube, flared
1
19 158–884 SP
ACER, flange, leather
2
20 103–420
PIN, spring
2
21 101–354
PIN, straight, spring
2
22 217–468 HOSE, hydraulic supply
, nylon, 3/4” ID,
cpld 1–1/16” fbe, 24.75” (628 mm)
1
23 178–751 GUARD, fan 1
24 179–714 SPACER 1
25 100–213
NIPPLE, pipe, 3/8 npt x 3”
1
26 217–469
FRAME, pump
1
27 101–578 CAPSCREW
, hex head, no. 8–32 x 0.38”
4
28
100–214
LOCKW
ASHER, spring, 5/16”
29
217–022
MOTOR, hydraulic
see manual 307–158 for parts
1
30 177–757
LABEL, identification
1
31
101–566
NUT
, lock, 3/8–16
32 106–212 CAPSCREW
, 3/8–16 x 2-3/4”
2
33 177–765 PLUG 2
34 177–652 HANDLE 1
35
168–210
NUT
, shouldered
1
36 168–21
1
COUPLING, connecting rod 1
37 160–327 ADAPTER, 90
union; 3/4 npt(m)
x 3/4 npt(f) swivel
1
38 161–800
ADAPTER, 3/4 npt x 3/8 npsm (fbe)
1
39 214–570
FLUID FIL
TER
SEE 307–273 FOR P
ARTS
1
40 235–497 CHECK VAL
VE, cpld 3/4 npt(fbe)
1
41 501–175 ELBOW
, pipe, 3/4 npt (mbe)
1
42
102–000
BUSHING, 1–1/2” x 1” npt
1
43
214–959
HOSE, suction,
1”npt(mbe), 1” ID, 6 ft
(1.8 m) long, spring guard both ends
1
44 169–528
TUBE, suction, 1” npt
1
45 101–552 ELBOW
, street, 90
, 1–1/2” npt
1
46 217–530 DISPLACEMENT PUMP ASSY, 1
see manual 307–862
for parts
47 609–822
ROD, tie, 13.88” (351 mm)
3
48
101–712 NUT
, lock, type “E” 5/8”– 1
13
49
100–101 CAPSCREW
, hex head, 3/8–16 x 1”
5
50
104–444
O–RING, VITON 1
51
104–126
PLUG, box, 3/4”
1
52
107–049
INSERT
, hose, 3/4 npt(f)
1
53
178–791
HOSE, suction, 1” ID, 3’ (9.9 m)
1
54
101–818
CLAMP
, hose, for 13/16” to 1–1/2” OD
2
55
178–773
LEG, frame
1
56
177–641
WASHER, flat 2
57
177–570
AXLE 1
58 177–656 FOOT BRACE 1
59 101–725 TIP
, rubber
1
60
177–585
PLA
TE, engine
1
61
216–141
SUPPORT
, engine
1
62
100–468
CAPSCREW
, hex hd, 3/8 x 1.5”
4
63
104–766
MOUNT
, motor
4
64
100–023
WASHER, 3/8”
65
178–754
SP
ACER, engine
4
66
100–133
LOCKWASHER, 3/8” 8
67
100–531
CAPSCREW
, hex hd, 3/8 x 2.5”
4
69
178–932
LABEL, caution
1
70
178–753
GUARD, muffler 1
71
218–125
RESERVOIR KIT 1
72
185–951*
LABEL, DANGER 1
73
100–538
SCREW
, hex head, 5/16–18 x 1/2”
6
74
100–188
NUT
, heavy hex, 5/16–18 unc–2a
75 178–137
LABEL, identification
1
76
106–053
ELBOW
, 90
, 1–1/16” thread
1
77
217–504
HOSE, hydraulic return
1” ID, cpld 1–5/16” x 1/2”
1
78
107–127
ADAPTER, male, 1–5/16” x 3/4”
1
79
620–188
ADAPTER, manifold, 1” (m) x
3/4 x 1/2 x 3/8 (f)
1
82
105–430
NUT
, seal, 1” npt
1
83
179–715
SHIELD, heat
1
85
178–795
HOSE, cooler
, 0.625”, 10.5” lg
1
87
LABEL, identification
1
88
178–935
LABEL, caution
1
89
100–103
PIN, cotter
, 0.125” dia, 1.5” long
2
90 101–936 NUT
, hex jam, 3/4”–10
1
91 168–212 ROD, connecting 1
92 158–674 P
ACKING, o–ring, buna–n
1
93 107–125 ELBOW
, 90
street, 3/4 npt(m)
1
94 105–429 NUT
, seal, 3/4 npt
1
95 178–750
FITTING, return, 1” npt(m)
x 3/4 npt(f)
1
96 178–794 FIL
TER, fluid
1
97 500–054 BUSHING, hex hd 1
98 107–067
O–RING, buna–n
1
103 101–845 SCREW
, self–tapping, no. 6 x 3/8”
1
104 103–181 LOCKW
ASHER, ext., no. 6
1
105 219–099
KNOB, pump
1
106 100–187 NUT
, hex, 5/16”
1
107 178–873 PUMP
, vane, hydraulic
1
108 100–421 SETSCREW
, 5/16” X 3/8”
2
109 106–063 COUPLER 2
110 605–358 KEY
, 1/4”
2
111 217–284 ENGINE, 10 HP 1
112 107–143 CAPSCREW
, sch, 7/16 x 1.25”
4
113 100–052 LOCKW
ASHER, spring, 7/16”
4
114 178–792 BLOWER 1
115 178–788 COOLER 1
116 178–861 PAD 2
117 178–786 SUPPORT
, pump
1
118 106–106
HITCH, foot brace
1
130 106–229 NIPPLE 1
131 206–994
TSL, 8 oz.
not shown
1
132 185–016
LABEL, Caution
1
137 100–004 CAPSCREW
, hex hd, 3/8–16” x 1.25”
2
138 107–032 ELBOW
, 90
street, 3/8 npt (m x f)
1
139 158–683 ELBOW
, 90
, 3/8 npt(mxf)
1
140 108–426
O–RING, buna–n
1
141 183–574
HOSE, rubber tube, 4.5”
1
142 183–575
NIPPLE, barbed hose, 3/8–18 npt(f)
1
143 222–011 GROUND WIRE & CLAMP 1
144 222–198 VAL
VE, pressure drain
1
145 100–176
REDUCER, pipe, 3/8 m x 1/4 f
1
*Replacement
DANGER and W
ARNING labels are available
at
no
charge.
