Maintenance
18 313536U
Proximity Switch Replacement
Procedure
1. Perform pressure relief procedure. See Pressure
Relief Procedure on page 15.
2. Remove proximity switch cable attached to proxim-
ity switch.
3. Remove proximity switch from rear of gun body.
4. Install new proximity switch.
5. Attach proximity switch cable to proximity switch.
FIG. 18
