Graco GX-16 - Gun Handle Model 26 C463

Parts
313536U 35
Gun Handle Model 26C463
927
907
Pinout
926
908
923
925
922
924
906
904
901
902
903
905
921
Ref. Part Description Qty
901 15K666 HANDLE, 2K dispense valve, electric 1
902 276745 STOP, trigger 1
903 112033 PIN, dowel 1
904 15B209 TRIGGER, gun 1
905 192272 PIN, pivot 1
906 203953 SCREW, cap hex hd 1
907 15K668 PLUNGER, trigger, 2K handle 1
908 551396 SPRING, .26 x .37 x .51 music wire 1
922 16H435 ISOLATOR, handle, GX-16 to MD2 1
923 16H436 ISOLATOR, handle, GX-16 to MD2, left 1
924 16H437 ISOLATOR, handle, GX-16 to MD2, right 1
925 122694 SCREW, bhsc, 10 x 1.00, ms 2
926 121070 SCREW, machine, #8 x 1.375 2
927 25E988 KIT, led handle 1
