Trigger Lock
313536U 9
Trigger Lock
Verify that the trigger lock is engaged whenever you stop pouring to avoid accidental triggering. Check daily for
chemical build-up on trigger, trigger lock, and trigger lock spring that can prevent proper trigger lock function.
Engage
To engage the trigger lock, release the trigger. The trig-
ger lock is spring loaded and automatically engages
when the gun trigger is released.
To engage the trigger lock, press the trigger lock down.
Disengage
To disengage the trigger lock, press trigger lock down.
See the following figure.
To disengage the trigger lock, press the trigger lock up.
FIG. 1: Models 257509, 257510
FIG. 2: Kit 24K223
FIG. 3: Models 257509, 257510
FIG. 4: Kit 24K223
