Dimensions
ti12896a
A
B
C
Model 257496 shown
Model
Dimension
ABC
257492, 257493,
257494, 257495
15.1 (383) 9.6 (244) 7.9 (201)
257497, 257502,
257503, 257504,
24E877, 24E878,
24K233, 24K234
(no hoses)
10.3 (262) 3.6 (91) 3.7 (94)
257496, 257507,
26C466, 25E975
9.3 (236) 3.0 (76) 8.9 (226)
257505, 257506 9.3 (236) 3.0 (76) 8.1 (206)
257498, 257499,
24J187, 24E876,
25E973, 25E974
9.3 (236) 2.8 (71) 3.7 (94)
