Parts
313536U 21
* For all models, o-ring materials are marked on the
gun below the A side orifice
 Parts are used in the maintenance of the gun. Parts
are shipped loose.
. 101d . 122679 . O-RING, epr, #902 1 1 1
102
257509 HANDLE, GX-16, pistol grip 1
257510
HANDLE, GX-16, pistol grip,
isolated 1 1 1
103 122694 SCREW, bhsc, 10-32x1.00, ms 2 2 2 2
104
122707
O-RING, fluoroelastomer,
#904, 75a 4 4 4 6 6 6 3 3
105 122714 O-RING, ep, 904, 70a 2 2 2 2 2
106
122713 SWITCH, proximity 1 1 1 1 1 1
15Y178 PLUG, cavity, proximity switch 1 1
107
257724
RESTRICTOR, orifice assy,
0.061 1 1
257717
RESTRICTOR, orifice assy,
0.039 1
108*
168518
PACKING, o-ring, fluoroelasto-
mer 1
109* 261500 O-RING, #902, fluoroelastomer 1
110
257701
RESTRICTOR, orifice assy,
0.011 1 1
257717
RESTRICTOR, orifice assy,
0.039 1
111* 285967 O-RING, #006 epr 1
112* 122679 O-RING, epr, #902 1
113 15Y177 FITTING, 7/16 org x 7/16 jic ext 1 1 1 1 1 1 1 1
114
298408 FITTING, 7/16 org x 9/16 jic ext 1 1 1 1 1 1
122710
ADAPTER, jic05xsae04, mm,
ss, 6k
1 1
115
122711
FITTING, elbow, 90,
jic04xsae04
1 1 1 1 1 1 1 1
116
122708
ADAPTER, swivel,
jic06xsae04, fm, ss, 6k
1 1 1 1 1 1
122709
ADAPTER, swivel,
jic05xsae04, fm, ss, 6k
1 1
117
122709
ADAPTER, swivel,
jic05xsae04, fm, ss, 6k
1 1 1 1 1 1
122708
ADAPTER, swivel,
jic06xsae04, fm, ss, 6k
1 1
118
122710
ADAPTER, jic05xsae04, mm,
ss, 6k
1 1 1 1 1 1
298408 FITTING, 7/16 org x 9/16 jic ext 1 1
Ref. Part Description
Quantity by Model
257496 257498 257499 257505 257506 257507 24J187 24E876
