Parts
313536U 23
 Parts are used in the maintenance of the gun. Parts
are shipped loose.
Ref. Part Description
Quantity by Model
257492 257493 257494 257495
201
257514 DISPENSER, GX-16, 24:1, pre-assy 1 1 1 1
. 201a . 122685 . PLUG, sae02, socket head, m, ms, 6k 1 1 1 1
. 201b . 261500 . O-RING, #902, fluoroelastomer 1 1 1 1
. 201c . 122687 . PLUG, sae02, 316 ss 1 1 1 1
. 201d . 122679 . O-RING, epr, #902 1 1 1 1
202
257594 HANDLE, GX-16, pour 1 1
257596 HANDLE, GX-16, pour 1 1
203
15Y246 BRACKET, hose, pour handle 1 1 1 1
204
122694 SCREW, bhsc, 10-32x1.00, ms 2 2 2 2
205
15Y247 BRACKET, hose, cylinder 1 1 1 1
206
122707 O-RING, fluoroelastomer, #904, 75a 4 4 4 4
207
122714 O-RING, ep, 904, 70a 2 2 2 2
208
285874 FITTING, 7/16 o-ring x 1/4 tube 90 elbow 1 1 1 1
209
122741 SCREW, bhcs, 1/4-20x0.50, ms 2 2 2 2
210
122730 ADAPTER, 1/4nptxsae04, fm, ss, 6k, 316 2 2 2 2
211
122731 ADAPTER, 1/4nptxsae04, fm, ms, 6k 2 2 2 2
212
122729 ADAPTER, 1/4nptx3/8tube, mf, ms, 5k 2 2 2 2
213
122732 ADAPTER, 1/4nptx3/8tub, mf, ss, 5k 2 2 2 2
214
122733 ADAPTER, sae04x1/4tub, mf, ms, 5k 1 1 1 1
215
15Y332 TUBE, a-return, left side 1 1
15Y326 TUBE, a-return, right side 1 1
216
15Y333 TUBE, a-supply, left side 1 1
15Y327 TUBE, a-supply, right side 1 1
217
15Y334 TUBE, b-return, left side 1 1
15Y328 TUBE, b-return, right side 1 1
218
15Y335 TUBE, b-supply, left side 1 1
15Y329 TUBE, b-supply, right side 1 1
219
15Y336 TUBE, hyd open, left side 1 1
15Y330 TUBE, hyd open, right side 1 1
220
15Y337 TUBE, hyd close, left side 1 1
15Y331 TUBE, hyd close, right side 1 1
221
122734 ADAPTER, 1/8nptx1/4tub, ff, ms, 5k 2 2 2 2
222
122735 ADAPTER, 1/4nptx3/8tub, ff, ms, 5k 2 2 2 2
223
122736 ADAPTER, 1/4nptx3/8tb, ff, ss, 5k, 316 2 2 2 2
224
122721 ADAPTER, swivel, jic6x1/4npt, fm, ms, 5k 1 1 1 1
225
122737 ADAPTER, swivel, 1/4nptxjic05, fm, ss, 6 1 1 1 1
226
122727 ADAPTER, jic05x1/4npt, mm, ss, 6k, 316 1 1 1 1
227
122722 ADAPTER, jic06x1/4npt, mm, ms, 6k 1 1 1 1
228
122726 FITTING, adapter, jic04x1/8npt 2 2 2 2
229
122742 SCREW, fhcs, 1/4-20x0.750, ms 2 2 2 2
230
122713 SWITCH, proximity 1 1 1 1
231
257724 RESTRICTOR, orifice assy, 0.061 1 1 1 1
232
168518 PACKING, o-ring, fluoroelastomer 1 1 1 1
233
261500 O-RING, #902, fluoroelastomer 1 1 1 1
234
257701 RESTRICTOR, orifice assy, 0.011 1 1 1 1
235
285967 O-RING, #006 epr 1 1 1 1
236
122679 O-RING, epr, #902 1 1 1 1
