Graco GX-16 - Page 25

Parts
313536U 25
 Parts are used in the maintenance of the gun. Parts are shipped loose.
303
257701 RESTRICTOR, orifice assy, 0.011 1 1
257717 RESTRICTOR, orifice assy, 0.039 1 1 1
304 168518 PACKING, o-ring, fluoroelastomer 1 1 1 1
305
285967 O-RING, #006 epr 1
168518 PACKING, o-ring, fluoroelastomer 1 1 1
306 261500 O-RING, #902, fluoroelastomer 1 1 1 1
307
122679 O-RING, epr, #902 1
261500 O-RING, #902, fluoroelastomer 1 1 1
308 122707 O-RING, fluoroelastomer, #904, 75a 3 3 3 3 3
309
122714 O-RING, fluoroelastomer, #904, 75a 2 2 2
122707 O-RING, fluoroelastomer, #904, 75a 2 2
310 15Y177 FITTING, 7/16 org x 7/16 jic ext 1 1 1 1 1
311 122713 SWITCH, proximity 1 1 1 1 1 1
312
298408 FITTING, 7/16 org x 9/16 jic ext 1 1 1 1
122710 ADAPTER, jic05xsae04, mm, ss, 6k 1
313
122720 ADAPTER, jic06xsae04, mm, ms, 6k,
fluoroelastomer
1 1 1
124221 ADAPTER, jic05xsae04, mm, ss, 6k 1 1
314
122717 ADAPTER, swivel, jic06xsae04, fm,
ms, 6k
1 1 1
125541 FITTING, swivel, jic05xsae04, fm, ss,
6k
1 1
315
129342 FITTING, elbow, swivel, 90, jic06, fm,
ss
2 2 2
122715 FITTING, elbow, swivel, 90, jic05, fm,
ss
2 2
316
122715 FITTING, elbow, swivel, 90, jic05, fm,
ss
2
129342 FITTING, elbow, swivel, 90, jic06, fm,
ss
2 2 2 2
317
122718 FITTING, elbow, swivel, 90, jic04, fm,
ms
2 2 2 2 2
318
122708 ADAPTER, swivel, jic06xsae04, fm,
ss, 6k
1 1 1 1
122709 ADAPTER, swivel, jic05xsae04, fm,
ss, 6k
1
319 122711 FITTING, elbow, 90, jic04xsae04 1 1 1 1 1
320 24C481 HOSE, 3 ft, A-supply, yellow tape 1
321
24C482 HOSE, 3 ft, A-return, yellow/white
tape
1
322 24C483 HOSE, 3 ft, B-supply, green tape 1
323 24C484 HOSE, 3 ft, B-return, green/white tape 1
324 24C485 HOSE, 3 ft, hydraulic open, black tape 1
325
24C486 HOSE, 3 ft, hydraulic close,
black/white tape
1
Ref. Part Description
Quantity by Model
257497 257502 257503 257504 24E877 24E878
